Summit Machine Tool
VS Series Vertical Mills
Description
The rugged Summit® V-series Vertical Mills have been engineered and manufactured from the finest components with the operator in mind. All controls of this vertical milling machine are centralized for ease of operation in either hand or power feed mode. Movement of the head to various angles is easily obtained from the operator’s position. The Summit V-series Vertical Mills are versatile enough to effectively serve small one-man machine shops, job shops, R&D departments, tool rooms and maintenance shops, as well as large, sophisticated manufacturing operations.
Standard Features
- Heavy Mehanite cast construction
- Heavy box saddle
- Huge box type ways on knee (VS-350B & VS-550B)
- Double table locks
- Turcite-B inserted guideways for extended machine life
- Complete electrics with low voltage controls for safer machine operation
- Way wipers for saddle and column
- Hardened & ground ways
- Power raise on knee (VS-550B)
- Power draw bar (VS-550B)
- R-8 collet set (V-242B & VS-350B)
- One-shot lubrication
- Draw bar
- Way covers
- Operation & parts manual
Included Accessories
- Built-in coolant system
- Halogen work light
- Clamping kit
- Service wrenches & tool box
| Specifications: | VS-350B | VS-550B |
| Motor size (2 speeds) | 3 HP | 5 HP |
| Spindle speeds – number | Inf. variable | Inf. variable |
| Spindle speeds – range | 60-4200 RPM | 80-3500 RPM |
| Spindle taper | R-8 | 40 taper |
| Spindle travel | 5″ | 5.5″ |
| Spindle feed range | .0015/.003/.006 IPR | .0015/.003/.006 IPR |
| Head movement (side to side) | +/- 90° | +/- 90° |
| Head movement (front to back) | +/- 45° | N/A |
| Table size (WxLxH) | 10″x50″x3-1/8″ | 11″x52″x3-1/8″ |
| Table feed (longitudinal) | 36″ | 32″ |
| Table feed (cross) | 16″ | 16″ |
| Max weight of work piece | 850 lbs. | 990 lbs. |
| Rotation of over arm | 360° | 360° |
| Over arm adjustment | 22″ | 24″ |
| Spindle nose to table | 2 1/2″ – 18 1/2″ | 2″ – 22″ |
| Weight | 2,900 lbs. | 3,740 lbs. |
| Specifications: | VS-350B |
| Motor size (2 speeds) | 3 HP |
| Spindle speeds – number | Inf. variable |
| Spindle speeds – range | 60-4200 RPM |
| Spindle taper | R-8 |
| Spindle travel | 5″ |
| Spindle feed range | .0015/.003/.006 IPR |
| Head movement (side to side) | +/- 90° |
| Head movement (front to back) | +/- 45° |
| Table size (WxLxH) | 10″x50″x3-1/8″ |
| Table feed (longitudinal) | 36″ |
| Table feed (cross) | 16″ |
| Max weight of work piece | 850 lbs. |
| Rotation of over arm | 360° |
| Over arm adjustment | 22″ |
| Spindle nose to table | 2 1/2″ – 18 1/2″ |
| Weight | 2,900 lbs. |
| Specifications: | VS-550B |
| Motor size (2 speeds) | 5 HP |
| Spindle speeds – number | Inf. variable |
| Spindle speeds – range | 80-3500 RPM |
| Spindle taper | 40 taper |
| Spindle travel | 5.5″ |
| Spindle feed range | .0015/.003/.006 IPR |
| Head movement (side to side) | +/- 90° |
| Head movement (front to back) | N/A |
| Table size (WxLxH) | 11″x52″x3-1/8″ |
| Table feed (longitudinal) | 32″ |
| Table feed (cross) | 16″ |
| Max weight of work piece | 990 lbs. |
| Rotation of over arm | 360° |
| Over arm adjustment | 24″ |
| Spindle nose to table | 2″ – 22″ |
| Weight | 3,740 lbs. |
